Understanding the Specifications and Models of Reinforced Welded Mesh is a crucial step in selecting the product that meets your project’s design and technical requirements.
- Key Specification Parameters
Wire Diameter (D): Typically ranges from D4 mm to D12 mm (e.g., D6, D8, D10). A larger diameter provides higher load-bearing capacity.
Grid Spacing (A x B): Common spacing ranges from 50×50 mm to 200×200 mm (e.g., 100x100mm, 150x150mm, 200x200mm). Closer spacing results in greater stiffness.
Weight per Square Meter (kg/m²): A key parameter for material cost calculation, directly determined by the wire diameter and grid spacing.
- Types & Surface Treatment Classification
Standard Welded Mesh (Black Steel / Bright): A cost-competitive option, used in structures where it is fully protected by concrete cover.
Galvanized Welded Mesh: Features a protective zinc coating, offering excellent corrosion resistance. This is the essential choice for humid environments, coastal areas, or where concrete cover is minimal.
- Standard Panel Sizes & Customization
We supply standard panel sizes (e.g., 2.4m x 6m) and can provide precise cutting to orderbased on your project drawings.
Selecting the correct specification directly impacts your project’s core benefits — durability and safety — as well as its economic efficiency. Once the specification is chosen, proper handling, storage, and installation are the next critical steps to ensure quality. Need a complete specification sheet or technical consultation? Contact us now.
